Kipp & Zonen CSD3 Sunshine Duration Sensor
The Kipp & Zonen CSD3 is a sunshine duration sensor that uses three photodiodes to detect when direct solar irradiance exceeds the WMO sunshine threshold of 120 W/m², switching a high/low output to record sunny versus non-sunny conditions. It has no moving parts and runs from 12 VDC with built-in heaters to shed rain, snow and frost.
- Supply
- 12 VDC
- Spectral range
- 400 to 1100 nm
- Operating temperature
- -40 to +70 °C
Overview
In detail
How it works
Three photo-diodes with specially designed diffusers make an analogue calculation of when it is sunny, as defined by WMO: the time during which direct solar radiation exceeds 120 W/m². The output switches high or low to indicate sunny or non-sunny conditions, and the calculated direct irradiance value is also available.
Construction
The CSD3 has no moving parts, improving on older Campbell-Stokes sunshine duration recorders. Built-in heaters dissipate rain, snow and frost and are normally switched externally, with an optional internal thermostat control available. It has a waterproof plug and socket connection, a humidity indicator, and a 5-year warranty.
Power
CSD3 operates from 12 VDC power.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Spectral range
- 400 to 1100 nm
- Operating temperature
- -40 to +70 °C
- Supply voltage
- 12 VDC
- Sunshine signal
- 1 ±0.1 V (direct radiation > 120 W/m²)
- Accuracy
- > 90% (monthly sunshine hours); > 90% (direct signal, clear sky)
- Analogue output signal
- 1 mV/W/m²
- Non-stability
- < 2 % change/year
- Response time
- < 1 ms
