DiTemp Light Reading Unit
The DiTemp Light Reading Unit is an entry-level Raman OTDR interrogator for distributed temperature sensing, measuring along fiber optic sensing cables up to 4 km with 2 m spatial resolution and a 10 second measurement time.
- Range
- 0-4 km
- Spatial resolution
- 2 m
- Sampling resolution
- 2 m
Overview
In detail
How it works
Uses the same Raman OTDR measuring principle as the rest of the DiTemp range to measure a full temperature profile over a fiber optic sensing cable, with a built-in 4-channel multiplexer.
Deployment
Rated for 0°C to 40°C operation (-15°C to +65°C storage), the unit connects via RS-232, Modbus or Ethernet/TCP through the DiView software, plus a volt-free alarm module for interfacing with plant control systems.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Range
- 0-4 km
- Spatial resolution
- 2 m
- Sampling resolution
- 2 m
- Temperature resolution
- 0.1°C
- Number of channels
- 4 ch, built-in multiplexer
- Fiber typology
- MMF 50/125 µm (ITU-T G.651)
- Operating temperature
- 0°C to 40°C
- Storage temperature
- -15°C to +65°C
- Humidity
- 5% to 95% RH, non-condensing
- AC power
- 100V-240V, 50Hz-60Hz
- DC power
- 24V or 48V options
