d-Tilt-SG MEMS Tiltmeter
The d-TILT-SG is a fully waterproof, dual-axis MEMS tiltmeter built around an accelerometer chip, designed for in-place borehole or surface deployment.
- Range
- ±30° (dual-axis)
- Output
- RS485 (9600,8,N,1) ASCII, up to 100 chars/reading, transmits over 1000 ft
- Resolution
- 0.01 arcdeg
Overview
In detail
How it works
A dual-axis MEMS accelerometer's duty-cycle digital signal is processed on-board to give a typical accuracy of 0.025 arcdeg at 0.01 arcdeg resolution. Each sensor is individually calibrated and temperature-compensated by an incorporated digital temperature sensor, and is shock-rated to 1000 g.
The RS485 output is an ASCII-encoded message carrying sensor ID, sensor type and temperature/tilt data directly in real-world units (arcdeg and °C).
Deployment
Suited to moderate-resolution slope, backfill, fault, pillar and bulkhead monitoring in non-retrievable applications. The signal transmits over 1000 ft without amplification; data can be logged for up to 3 months on a data logger or networked over TCP/IP. Housing is 65 x 58 x 35 mm, supplied with 10 m of leadwire.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Range
- ±30° (dual-axis)
- Resolution
- 0.01 arcdeg
- Accuracy
- Tilt better than ±0.025 arcdeg; temperature ±2°C
- Output
- RS485 (9600,8,N,1) ASCII, up to 100 chars/reading, transmits over 1000 ft
- Operating temperature
- -20°C to 85°C
- Dimensions
- 65 x 58 x 35 mm; 10 m leadwire supplied
- Sensor technology
- Dual-axis MEMS accelerometer, shock-rated to 1000 g
