Numerical photometer: PHOTOPOD
Built around "plug and play" digital sensor technology, the ODEON-PHOTOPOD is an intelligent and reliable system for water analysis. It boasts 70 chemical methods, including COD, nitrogen, nitrates and more, and connects easily to the ODEON multi-parameter device or to your PC.
- Instrument type
- Diode-based photometer for water analysis
- Wavelengths
- 639 nm, 591 nm, 518 nm, 468 nm, 400 nm
- Wavelength adjustment
- Automatic
Overview
In detail
Applications
This instrument can be used to analyse many different water sources — for example urban, municipal and industrial waste water, drinking water, boiler and cooling tower water, and natural waters.
Features
Photometer with LED technology for water analysis.
Minimal dimensions and optimised handling.
Strong and waterproof Fischer metallic connections.
Measurement principle
The PHOTOPOD is a diode-based photometer with integrated filters that communicates with the ODEON via a digital link. Blank measurements are stored electronically, and measurement is direct for concentration, absorbance or transmittance.
PC connection
Connect the PHOTOPOD to your computer via the free downloadable SPECTRALAB software, compatible with Windows 10, to display and save your concentration results directly.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Instrument type
- Diode-based photometer for water analysis
- Chemical methods
- 70 chemical methods, including COD, nitrogen and nitrates
- Wavelengths
- 639 nm, 591 nm, 518 nm, 468 nm, 400 nm
- Wavelength adjustment
- Automatic
- Detector
- Silicon photodiode
- Cell support
- For round cells, 16 mm in diameter
- Measurement
- Direct for concentration, absorbance or transmittance
- Blank measurements
- Electronic storage
- Signal interface
- RS-485 digital
- Connection
- ODEON multi-parameter device or PC
- Dimensions
