Lufft WS200 Compact Weather Sensor
The Lufft WS200 is a compact, all-in-one ultrasonic sensor that simultaneously measures wind speed and wind direction, with no moving parts to service. It is built to IEC 61724-1:2017 standards for high-end applications such as solar monitoring.
- Ingress
- IP66
- Supply
- 11 to 32 VDC; 24 VDC ±10% for heater
- Dimensions
- Ø approx. 150 mm, height approx. 223 mm
Overview
In detail
How it works
The WS200 uses ultrasonic sensing to measure wind speed and wind direction simultaneously, with data processing built into the unit. With no moving parts, it is robust and largely maintenance-free even in harsh environments. It ships as standard with Modbus communications; SDI-12 output can be supplied on request, and an optional surface temperature probe can be fitted for applications such as measuring back-of-panel temperature in PV solar installations.
Mounting
The sensor mounts directly onto a 60 mm diameter pole using the supplied 'U' mounting brackets, or via an optional mounting arm that attaches to 40-80 mm diameter poles.
Connectivity
Communication is via an RS485 interface supporting UMB-Binary, UMB-ASCII, Modbus-RTU, Modbus-ASCII, XDR or SDI-12 protocols, giving compatibility with most commercially available Met/HydroMet data loggers and PLC systems through an open communication protocol.
Reach out and say hi
Specifications
Technical specifications
- Dimensions
- Ø approx. 150 mm, height approx. 223 mm
- Weight
- Approx. 0.8 kg
- Interface
- RS485, 2-wire, half-duplex
- Supply voltage
- 11 to 32 VDC; 24 VDC ±10% for heater
- Power consumption
- 20 VA (heater)
- Operating temperature
- -50 to 60°C (with heater)
- Operating relative humidity
- 0 to 100% RH
- Cable length
- 10 m
- Ingress
- IP66
- Standards
- Compliant to IEC 61724-1:2017
- Mast mounting
- Suitable for mast diameter 60-76 mm
