eTelecast Antenna and Display System
The eTelecast is a turnkey satellite ground station that receives pre-processed geostationary meteorological data, offering an alternative where direct broadcast reception is impractical. It integrates with ESS's Proteus visualization and analysis software and outputs standard formats including GeoTIFF, JPEG, netCDF and HDF5.
- Frequency bands
- Ku-Band and C-Band
- Transmission standard
- DVB and DVB-S2
- Output formats
- GeoTIFF, JPEG, netCDF, HDF5
Overview
In detail
How it works
eTelecast receives pre-processed geostationary data from communications satellites via multiple antenna and receiver options, supporting both Ku-Band and C-Band DVB and DVB-S2 transmissions. It is suited to different dissemination services, geographical locations and service requirements.
Data sources
The ground station is compatible with EUMETCast, GEONETCast, HIMAWARI-Cast and CMA-Cast rebroadcast services.
Software and output
eTelecast integrates with ESS's Proteus visualization and analysis software and provides a wide variety of standard data interchange output formats, including GeoTIFF, JPEG, netCDF and HDF5.
Delivery
eTelecast is supplied as a turnkey system: manufacturing and engineering, installation and training are all provided, with all hardware and software required to collate and analyse rebroadcast meteorological data.
Reach out and say hi
Specifications
Technical specifications
- Frequency bands
- Ku-Band and C-Band
- Transmission standard
- DVB and DVB-S2
- Output formats
- GeoTIFF, JPEG, netCDF, HDF5
- Data sources
- EUMETCast, GEONETCast, HIMAWARI-Cast, CMA-Cast
- Software
- Proteus visualization and analysis
