Digital Piezometer
This is a Casagrande-tip standpipe piezometer for boreholes and observation wells, built from perforated PVC with an internal filter element for corrosion resistance and long-term reliability.
- Dimensions
- 40.6 mm O.D. x 345 mm
- Filter material
- Spun nylon, 70 micron pore diameter
- Permeability
- 3 x 10⁻⁴ m/s (low air entry)
Overview
In detail
How it works
The Casagrande tip comprises a perforated PVC body around an inner spun-nylon filter element with a 70 micron pore size, giving a permeability of 3 x 10⁻⁴ m/s (low air entry). It connects to lengths of 25NB PVC pipe and is installed in a borehole within a sand response zone, sealed above with bentonite and backfilled to surface.
Standpipe piezometers with Casagrande tips suit high-permeability soils where time-lag and high-volume displacement are not critical.
Reading
Water level in the PVC standpipe is read using a water level indicator (dipmeter) or Water Whistle, and used to calculate piezometric pressure or groundwater level. Standpipes subject to artesian groundwater can be fitted with a Bourdon-type pressure gauge instead.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Dimensions
- 40.6 mm O.D. x 345 mm
- Filter material
- Spun nylon, 70 micron pore diameter
- Permeability
- 3 x 10⁻⁴ m/s (low air entry)
- Weight
- 0.150 kg
- Filter area
- 245 cm²
- Pipe connection
- 25NB PVC pipe
