d-Civil Exto
The D Civil Exto is a Yieldpoint borehole extensometer built from polycarbonate, stainless steel and aluminium alloy, with an on-board microprocessor that reads ground displacement directly in millimetres to a resolution of 0.01 mm.
- Range
- Length up to 25 m (80 ft)
- Resolution
- 0.01 mm
- Accuracy
- 0.05 mm
Overview
In detail
How it works
An on-board microprocessor gives readings directly in millimetres, with a unique individual ID tag and an on-board temperature sensor for each unit. Resistance to stretching is manually adjustable for complete adaptability to soil and grout conditions, and high-profile anchor points give better tracking of soil movement. The instrument is completely immune to water and will keep working even if distal sections are lost.
Deployment
Anchor points are 6 in (150 mm) long and 1¾ in diameter, with steel washers for a secure grip in soft grout; the recommended grout mix is 5 parts water, 2 parts Portland cement and 1 part bentonite by weight. It is compatible with an Ethernet gateway, WiFi gateway or RF node, and stores up to 100 ASCII characters per reading.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Range
- Length up to 25 m (80 ft)
- Resolution
- 0.01 mm
- Accuracy
- 0.05 mm
- Dimensions
- 25 mm (1 in) diameter
- Anchor point
- 6 in long, 1¾ in diameter, with steel washers
- Materials
- Polycarbonate, stainless steel, aluminium alloy
- Compatibility
- Ethernet gateway, WiFi gateway, RF node
