Digital piezometers - d-Piezo
YieldPoint's d-Piezo is a digital piezometer that integrates a MEMS pressure transducer with a micro-controller to measure water pressure and depth, outputting readings directly in kPa and degrees Celsius over an RS485 digital signal. Each instrument carries a unique ID and can be run over long cable distances without amplification.
- Range
- 0-1000 kPa (unvented)
- Output
- RS485, transmitted to a data logger up to 500 m over 2 x twisted pair
- Resolution
- 0.01 kPa; approx. 1 mm of water over 100 m range
Overview
In detail
Measurement
The d-Piezo measures pressure from 0 to 1000 kPa (unvented) with 0.01 kPa resolution, equivalent to roughly 1 mm of water over a 100 m range. Temperature is measured from -35°C to +85°C with 0.1°C resolution.
Connectivity
The output signal is transmitted as an RS485 digital signal at 9600 bits/s (9600,9,n,1), ASCII encoded, to a data logger up to 500 m away over two twisted pairs. RS485 signals tolerate wet conditions and can be transmitted up to 1000 m without amplification; each instrument carries a unique ID so arrays of d-Piezos can be daisy-chained and remotely monitored.
Reach out and say hi
Let us help. Tell us the site, the range you expect and what it has to talk to, and we’ll work out the right variant, cable and mounting — and quote it.
Specifications
Technical specifications
- Range
- 0-1000 kPa (unvented)
- Resolution
- 0.01 kPa; approx. 1 mm of water over 100 m range
- Operating temperature
- -35°C to +85°C (0.1°C resolution)
- Output
- RS485, transmitted to a data logger up to 500 m over 2 x twisted pair
- Communication
- 9600 bits/s (9600,9,n,1), ASCII encoded, unique ID per instrument
